Fully Hydraulic Double Drive Single Drum Vibratory Roller Road Leveling Machine

Product Details

Place of Origin: China

Brand Name: RICALT

Certification: ISO9001

Model Number: RT202482

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: 21500-50000

Packaging Details: Nude Cargo

Delivery Time: 30 -50work days

Payment Terms: L/C, D/A, D/P, T/T

Supply Ability: 50 pcs/month

Get Best Price
Contact Now
Specifications
Highlight:

Fully Hydraulic road leveling machine

,

Single Drum road leveling machine

,

road leveler

Work Quality (kg):
26000
Excitation Force (kN):
500/360
Vibration Frequency (Hz):
29/35
Climbing Ability (%):
50
Engine Model:
WP4.6N
Rated Power/rated Speed (kW/rpm):
162/2200
Overall Dimensions Of The Machine (mm):
7000 × 2482 × 3370
Forward Speed (km/h):
0-10
Backward Speed (km/h):
0-10
Wheelbase (mm):
3570
Work Quality (kg):
26000
Excitation Force (kN):
500/360
Vibration Frequency (Hz):
29/35
Climbing Ability (%):
50
Engine Model:
WP4.6N
Rated Power/rated Speed (kW/rpm):
162/2200
Overall Dimensions Of The Machine (mm):
7000 × 2482 × 3370
Forward Speed (km/h):
0-10
Backward Speed (km/h):
0-10
Wheelbase (mm):
3570
Description
Fully Hydraulic Double Drive Single Drum Vibratory Roller Road Leveling Machine

Upgrading of driving and riding environment

● Extra large space roller cab;

●The top of the cabin air conditioning system is equipped with a fresh air exchange function;

●Standard luxury interior, new texture experience;

●No A-pillar design, wider field of view;

● Large storage space, making it more convenient to carry items.



Excellent operational performance

●Reduce the number of turns to 7 and the steering force to less than 20N;

●Excellent three-level shock absorption, capable of working continuously for 600 minutes without fear of fatigue during operation;

●The handle has the functions of reversing, switching between large and small vibrations, and starting and stopping vibrations, making the operation simpler;

●Equipped with 6 LED headlights as standard, fearless of night work;

●New dashboard, eight inch display screen, better human-computer interaction.



Excellent compaction performance

● No impact vibration wheel, smooth start stop vibration;

●Excellent loading and unloading ratio, high compaction and flatness;

●The compaction degree has reached the industry-leading level.



user-friendly design

● Set up front and rear trailer hooks for easy towing of vehicles;

●The water cup holder is integrated on the right control box;

●Equipped with a backup camera as standard, greatly improving safety;

● Equipped with a water level observation window for easy observation.



More convenient maintenance

●The maintenance filter element is centrally arranged, and the filter element can be replaced by opening the hood;

●Inverted engine for easy maintenance;

●The front end of the water tank is equipped with a dust-proof net for easier cleaning;

●Drain the engine oil and drain the water tank externally, reducing maintenance time.



Rich optional configurations

●Optional configurations: active avoidance system, density detection, full vehicle imaging, protruding wheels, electric push rod opening hood, personalized selection, worry free use of the machine.



Use more economically

● Dynamic control assembly technology, combined with automatic idle, ECO economy mode and other functions, reduces comprehensive fuel consumption by 15%;

●The engine requires an extended maintenance cycle of 500 hours, while the drive axle and vibration wheels require 1000 hours to reduce maintenance frequency.



Intelligentization

●Linde electronic hydraulic system provides closed-loop precise control of vibration frequency to improve compaction efficiency;

● Multiple frequencies to meet various working conditions, wide adaptability to working conditions, and high compaction efficiency;

●Real time speed display and constant speed control function, meeting the requirements of speed adjustment and constant speed under different working conditions;

● Manual (one button start stop vibration)/automatic two start stop vibration control modes, making operation simpler.
